EVB90427
Melexis EVB90427
The EVB90427 provides an easy way to connect the MLX90427 Triaxis® rotary & joystick position sensor to a microcontroller or measurement device.
Top features
-
Quickly connect to a microcontroller or measurement device
-
5V and 3V3 Application Compatible
-
High Speed Serial Interface (SPI compatible – Full Duplex)
Delivery Includes
- Evaluation board equipped with MLX90427GDC-AAC-900
- Version without pin header
- Dimension app. 30x32mm
If you require technical support please contact us.
Melexis MLX90427 Triaxis 3rd Generation Mainstream Embedded 3D Joystick, Linear & Rotary Hall-Position Sensor IC
ASIL-C | Full SPI | Integrated DSP | 360° Rotary Strayfield Robust | +160°C
ASIL-C capable, absolute measuring 3D joystick, linear and rotary Hall-position sensor IC with Melexis
Triaxis technology based on the Hall effect. Suitable for non-contact XYZ position detection as well as
for angular rotay (Triaxis IMC) and strayfield immune 360° rotary applications (dBz). This hybrid mode allows to acquire rotary 360° from legacy applications using Triaxis IMC technology and 360° strayfield robust
rotary applications with dBz signal at the same time. The integrated DSP can be fully operated by SPI commands.
A simple axial or diametal magnet is sufficient for control.
Features
- Integrated DSP for Alpha/Beta, XYZ, Linear, Angular Rotary or Joystick Applications
- 360° Rotary Stray Field Immune in dBz-Mode and Legacy Rotary in IMC-Mode (SOIC-8 only)
- 360° Legacy Rotary in IMC-Mode for dual DIE (TSSOP16)
- High Speed Full-SPI interface
- No need for PTC-04 programming
- ASIL-C Ready (ISO26262/SEooC)
- Functional compatible with MLX90333, MLX90363 or MLX90378
- Operating voltage 3V3 (3.0~3.6V) or 5V (4.5~5.5V)
- Single-DIE rotary SFI & IMC (SOIC-8) or Dual-DIE legacy IMC (TSSOP-16)
- Temperature range -40°C...+160°C (automotive) or -20°C...+85°C
- Chip revision "AAC“
(see data sheet for details)
If you have further questions please contact our team.
MLX90427 Triaxis® teaser for rotary & joystick position in industrial applications
Video about the MLX90427 rotary & joystick position IC for industrial applications
Video: Melexis Triaxis Gen.3 Sensor MLX90426 dBz Stray-Field Immune (SFI) compared to the competition
Video about the Melexis MLX9042x Magnetic Position Sensor IC Product Family
If you have further questions please contact our team.
Datasheet:
MLX90427 Datasheet
Flyer:
MLX90427 Product flyer
App-Note:
MLX90427 User Manual on SPI Commands
Selection Guide: Triaxis® position sensors selection guide for automotive market
Selection Guide: Triaxis® position sensors selection guide for industrial & consumer markets
Software:
Melexis MLX90427 - Labview GUI
Software:
Melexis MLX90427 - Firmware for Arduino®
